| Place of Origin: | China |
|---|---|
| Brand Name: | MCLLROY |
| Certification: | CE,ISO9001 |
| Model Number: | FE20 |
| Minimum Order Quantity: | 1 Set |
| Price: | 12000-15000 USD |
| Packaging Details: | Nude , 8 sets in 1 40HQ |
| Delivery Time: | 5-8 working days |
| Supply Ability: | 300 sets / month |
| Rate Loading: | 2000 Kg | Load Center: | 500 Mm |
|---|---|---|---|
| Battery Type: | Lead Acid | Wheel Base: | 1500 Mm |
| Tire Type: | Air,2F*2R Tire | Front Tire: | 7.0-12-12PR |
| Rear Tire: | 18*7-8PR | Overhead Guard Height: | 2140 Mm |
| Max.Extended Height: | 4030 Mm | Right-Angle Store Aisle: | 3930 Mm |
| Overall Length(without Fork): | 2400 Mm | Overall Width: | 1160 Mm |
| Overall Height(Mast Closed): | 2140 Mm | Total Weight(with Battery): | 4200 KG |
| Front Overhang: | 485 Mm | Angle Of Mast Inclination (forward /backward): | 6°/12° |
| Highlight: | 2 Mast Stage Electric Forklift,3000mm Lifting Height Electric Forklift |
||
1. Products Description of MCLLROY Electric Forklift
Greater Stability, Maximum Performance
Lifting loads up to 5.0 tonnes, the MCLLROY 4-wheel electric forklift is designed to significantly improve driver performance. It has a shorter turning radius, providing greater maneuverability in confined aisles. A four-wheeled chassis gives maximum stability, ideal for heavy-duty applications, whilst excellent visibility of the fork tips at any height for safe and confident driving.
Information on our four wheel electric forklifts for sale, including load capacity, lift height, mast type, can be found below.
2. Specification
| FE20 | FE25 | |
| Rate Loading Weight | 2000 KG | 2500 KG |
| Mast Stage | 2 | 2 |
| Lifting Height | 3000 mm | 3000 mm |
| Driven Motor Power(60 min) | 9 KW | 9 KW |
| Oil Pump Motor Power(15 min) | 11 KW | 11 KW |
| Battery | 48V/600Ah | 48V/600Ah |
| Battery Box Size | 500*900*760 mm | 500*900*760 mm |
| Motor& Controller Type | AC | AC |
| Transimission | Auto | Auto |
| Fork Size | 1070*122*40 mm | 1070*122*40 mm |
| Tire Type | Air | Air |
| Front Tire | 7.00-12-12PR | 7.00-12-12PR |
| Rear Tire | 18*7-8PR | 18*7-8PR |
| Overhead Guard Height | 2140 mm | 2140 mm |
| Max.Extended Height | 4030 mm | 4030 mm |
| Right-Angle Store Aisle (pallet 1200*1200mm) |
3930 mm | 3950 mm |
| Overall Length(without fork) | 2360 mm | 2400 mm |
| Overall Width | 1160 mm | 1160 mm |
| Overall Height(Mast closed) | 2140 mm | 2140 mm |
| Total Weight(with battery) | 4200 KG | 4200 KG |
| Front Overhang | 448 mm | 485 mm |
| Angle of Mast inclination (forward /backward) |
6°/12° | 6°/12° |
| Load Center | 500 mm | 500 mm |
| Mast Ground Clearance (full loading) |
110 mm | 110 mm |
| Center Ground Clearance (full loading) |
115 mm | 115 mm |
3. Details and Advantages of MCLLROY Electric Forklift
| FE20 | FE25 | |
| Rate Loading Weight | 2000 KG | 2500 KG |
| Mast Stage | 2 | 2 |
| Lifting Height | 3000 mm | 3000 mm |
| Driven Motor Power(60 min) | 9 KW | 9 KW |
| Oil Pump Motor Power(15 min) | 11 KW | 11 KW |
| Battery | 48V/600Ah | 48V/600Ah |
| Battery Box Size | 500*900*760 mm | 500*900*760 mm |
| Motor& Controller Type | AC | AC |
| Transimission | Auto | Auto |
| Fork Size | 1070*122*40 mm | 1070*122*40 mm |
| Tire Type | Air | Air |
| Front Tire | 7.00-12-12PR | 7.00-12-12PR |
| Rear Tire | 18*7-8PR | 18*7-8PR |
| Overhead Guard Height | 2140 mm | 2140 mm |
| Max.Extended Height | 4030 mm | 4030 mm |
| Right-Angle Store Aisle (pallet 1200*1200mm) |
3930 mm | 3950 mm |
| Overall Length(without fork) | 2360 mm | 2400 mm |
| Overall Width | 1160 mm | 1160 mm |
| Overall Height(Mast closed) | 2140 mm | 2140 mm |
| Total Weight(with battery) | 4200 KG | 4200 KG |
| Front Overhang | 448 mm | 485 mm |
| Angle of Mast inclination (forward /backward) |
6°/12° | 6°/12° |
| Load Center | 500 mm | 500 mm |
| Mast Ground Clearance (full loading) |
110 mm | 110 mm |
| Center Ground Clearance (full loading) |
115 mm | 115 mm |
4.Production lines:
A complete production process mainly includes: material procurement-steel plate cutting-welding-spray painting -drying-assembly-inspection
Welding:
Manual welding requires experienced workers, and the finished product is more likely to have variation in quality. If the welding robot is well adjusted, the quality will be more stable than manual welding. Our company now uses robot welding, there are currently 10 in total.By robotic positioner external axis servo motor rotation, combined with the robotic system trajectory interpolation, ensuring the smooth running accuracy and machine operation.
Good welding is done at once, so there will not be seam greater than 1mm. And fair welding will have break point. Whereas bad welding makes the seam too wide, they have to stuff iron in the side the seam and weld another layer outside. It is hard to tell from the appearance, but the integrity and strength of the finish product is totally different. You can tell the difference between the welding of our company and other company from the pictures here. (other has break point)
90% steel structure parts are made by ourselves, which can gurantee our forklift parts' mutual good match and great working performance.
